PANEL METERS
HMI's & Panel Meters
PANEL METERS
Red Lion offers the widest range of panel meters in the industry. Our meters are available in various sizes and capabilities including count, rate, time, voltage, current, process, strain gage and temperature inputs. With almost 4 million units sold, our panel meters are field proven, time tested and have earned the distinction of being the industry’s #1 brand for 16 years and counting.
Need help selecting the right meter? Try our Panel Meter Selector tool.
|
STANDARD METERS |
|
MINIATURE METERS |
|
PAX®2
Red Lion’s PAX®2 panel meters provide universal capabilities to deliver the ultimate in meters. Universal power (AC/DC), universal signal input and a built-in USB port allows easy programming with Crimson® software. Available in 1/8 DIN size models, PAX2 panel meters offer a wide range of field-installable option cards for communication, retransmitted analog output and setpoint. These panel meters also provide zone display color change at setpoint and NEMA 4X/IP65 protection. Learn more. |
aaddss |
CUB®5
Red Lion’s CUB®5 offers a large 0.48" (12 mm) reflective or backlit five or six digit LCD display and field-installable option cards. Communication and setpoint control can easily be added by installing an option card. These panel meters also provide display color change at setpoint, Crimson software programming and NEMA 4X/IP65 protection are standard.
|
|
PAX
The Red Lion PAX is the industry’s leading panel meter. Available in 1/8 DIN size models, the PAX offers a wide range of field-installable option cards for communication, retransmitted analog output and setpoint control. These panel meters offer 0.56" (14 mm) standard green or sunlight readable red LED displays, easy Crimson software programming and NEMA 4X/IP65 protection. Learn more. PAX LITE
Red Lion’s PAX Lite line of panel meters offer the perfect solution for basic monitoring applications. Available in 1/8 DIN size models, PAX Lite panel meters provide a large 0.56" (14 mm) red LED display and optional dual preset outputs to extend control capabilities. Scaling, NEMA 4X/IP65 protection and programmable decimal points are also included.
C48
The Red Lion C48 counters and timers are available in industry standard 1/16 DIN packaging. With a dual line display, users can view count or time alongside a secondary function such as batch or preset value. C48 counters and timers also provide multiple presets, NEMA 4X/IP65.
|
CUB4
For basic applications that require a large display, Red Lion's CUB4 is the perfect solution. The CUB4 features a large, easy-to-read from a distance .6" (15 mm) reflective or backlit display, several inputs and NEMA 4X/IP65 protection. Learn more. CUB7
Red Lion's CUB7 panel meters feature the smallest footprint of our product portfolio. Available in 1/32 DIN size models, CUB7 counters and timers are available with a 0.35" (9 mm) highly reflective or backlit eight digit LCD display. These meters also offer various wiring options, an internal lithium battery, remote reset and NEMA 4X/IP65 protection.
OTHER Other available models: DT8 panel meters. |
